Constructed from high-tensile structural carbon steel (S235JR / S275JR / S355JR), our warehouse racks undergo automated continuous roll-forming and robotic multi-axis welding to guarantee extreme load integrity in heavy manufacturing and distribution hubs.
Storing longitudinal and cylindrical materials—including seamless steel tubing, extruded aluminium profiles, ductile iron sewage conduit pipes, and structural copper conduits—presents complex mechanical challenges. Standard selective pallet racking is structurally incapable of handling the continuous horizontal deflection, concentrated shear line loads, and rolling hazards inherent to cylindrical stock. In Serbia’s accelerating industrial sectors across Vojvodina, the Šumadija basin, and Southern Morava, modern fabrication and supply facilities require dedicated cantilever pipe racking systems built to strictly defined European engineering codes.
Our pipe storage configurations are mathematically engineered and fabricated under CE Declaration of Performance (DoP), strictly complying with EN 15512 (Steel static storage systems – Adjustable pallet racking systems – Principles for structural design), EN 15620 (Tolerances, deformations and clearances), and Eurocode 3 (EN 1993-1-1) for structural steel design.
| Structural Parameter | Light-to-Medium Pipe Cantilever | Heavy Industrial Column Racks | Extra-Heavy Structural Tube Tower |
|---|---|---|---|
| Load Rating Per Arm (UDL) | 250 kg – 800 kg | 1,000 kg – 2,500 kg | 3,000 kg – 6,000 kg+ |
| Column Profile (Cold/Hot) | Roll-formed C/U Profile 200×60 | Hot-Rolled IPE 240 – IPE 360 | Structural HEA 300 – HEB 500 Beam |
| Steel Metallurgy Specification | S235JR (EN 10025-2) Yield 235 MPa | S275JR / S355JR Yield >355 MPa | S355J2 High Impact Resistance |
| Cantilever Incline Angle | 2.0° – 2.5° Positive Camber | 2.5° Positive Camber Under Load | Custom Machined Incline Stop Plate |
| Deflection Limits (δ) | δ ≤ L / 200 (EN 15620 Cl. 5) | δ ≤ L / 250 Serviceability Limit | δ ≤ L / 300 Heavy Machinery Standard |
| Seismic Coefficient Verification | SRPS EN 1998-1 Zone II (0.10g) | SRPS EN 1998-1 Zone III (0.15g) | Seismic Base Isolated (0.20g Balkan) |
| Corrosion Barrier Treatment | Electrostatic TGIC Powder (60–80μm) | Epoxy-Polyester Hybrid Dual Layer | Hot-Dip Galvanized ISO 1461 (>85μm) |
Seismic Safety Engineering for the Balkans: Serbia is geographically situated within the active Balkan tectonic zone, experiencing variable seismic risk categorised by peak ground acceleration ($a_g$) ranging from $0.10g$ to over $0.20g$ in regions such as Kopaonik, the Kolubara basin, and southern districts. Racking installations in logistics parks must not merely resist dead loads ($G_k$) and live tube storage loads ($Q_k$); they must be calculated against overturning moments induced by seismic forces ($E_k$) pursuant to SRPS EN 1998-1.
Our structural engineering office utilizes advanced 3D Finite Element Analysis (FEA) through RFEM and ANSYS to simulate nonlinear dynamic interaction between column uprights, tapered arms, and base assemblies. Every system supplied to Serbian logistics facilities incorporates heavy base plates with dual-axis structural anchoring via high-tensile European ETA-certified mechanical wedge anchors or chemical injection mortars (e.g., M16–M24 Grade 8.8 bolts) directly into C25/30 or C30/37 reinforced concrete slabs.
Serbia has established itself as Southeastern Europe's premier industrial and manufacturing bridgehead. Our certified pipe racking systems solve distinct material handling challenges across regional production nodes.
Home to premier Tier-1 and Tier-2 automotive component suppliers, the Kragujevac and Niš corridors handle high-precision hydraulic fluid conduits, stainless steel exhaust tubes, and structural steel chassis profiles. Storing these materials requires damage-free contact. Our pipe racking is equipped with high-density polyurethane (PU) arm liners, rubber bumper strips, and removable vertical end-stops, preventing surface scratching, ovalisation, and metallurgical cross-contamination during overhead crane and sideloading forklift cycles.
Surrounding the heavy steel manufacturing ecosystems of Smederevo and the vast civil engineering booms of the Belgrade Waterfront & EXPO 2027 urban expansions, contractors must warehouse massive volumes of structural hollow sections (SHS, RHS), scaffolding tubes, and API-spec pipeline components. Our heavy-duty IPE and HEA profile cantilever configurations allow high-capacity multi-level stacking up to 9 meters in clear building height, maximizing floor density while preserving 100% direct access to every bundle.
The petrochemical refineries of Pančevo and chemical plants throughout Vojvodina require strict inventory segregation of schedule-rated carbon steel, duplex stainless steel, and PVC-U/CPVC chemical conduits. Our corrosion-resistant cantilever pipe systems are custom treated with ISO 12944 compliant C3/C4 protective paint systems or hot-dip galvanisation, standing up to aggressive ambient airborne chemical vapours, humidity, and freeze-thaw cycles without zinc peel or frame degradation.
Modern third-party logistics (3PL) hubs situated in Stara Pazova, Inđija, and Šimanovci serve pan-European supply channels along the Danube waterway and Corridor X highway. Racking here must support rapid SKU turnover. Our double-sided cantilever pipe racks enable narrow aisle (VNA) operations with multidirectional reach trucks or automated guided vehicles (AGVs), providing instant throughput without double-handling buried pipe bundles.
Driven by strategic geographical positioning, competitive operational frameworks, and bilateral free-trade arrangements, Serbia's logistics real estate market is undergoing unprecedented technological modernization.
European OEMs are progressively relocating precision parts manufacturing from Far East origins to Southeastern Europe. Serbia is absorbing major manufacturing inflows, driving demand for heavy structural racking systems capable of storing long bar raw materials and finished piping right next to assembly lines.
With industrial land values rising in the Belgrade-Novi Sad conurbation, warehouse architects are converting from horizontal floor storage to 12-to-15 meter vertical cantilever configurations. Automated stacker cranes and rail-guided retrieval arms demand tight fabrication tolerances under EN 15620 Class 100/200.
Institutional developers (such as CTP, VGP, and domestic funds) require all building fixtures—including industrial storage racking—to comply with stringent ESG criteria. Our steel is 100% recyclable, fabricated via low-waste CNC roll lines and coated with VOC-free thermosetting powder.
Combining over two decades of heavy industrial fabrication with world-class logistics facilities, we provide direct factory-to-site engineering solutions without trading intermediaries.
Over two decades of pure-play focus on static warehouse engineering, heavy industrial cantilever systems, and structural mezzanines, serving over 500 major international corporate enterprises across 12 distinct industries.
Complete control of the fabrication chain under one roof: automated coil de-coiling, laser profiling, CNC punching, precision continuous roll-forming lines, robotic welding jigs, and an automated multi-stage pre-treatment powder coating line.
Our Quality Management System adheres to ISO 9001:2015. Every production heat is traceable back to mill test certificates (EN 10204 Type 3.1) with verifiable yield and tensile elongation tests, fully CE marked for structural execution (EN 1090-1 EXC2).
No generic off-the-shelf catalog templates. Our engineering department designs layout arrangements specifically accommodating your facility’s building columns, roof trusses, crane runways, and forklift turning radiuses, delivering complete CAD and static calculation books.
Components are bundled with corner edge protectors, heavy timber dunnage, anti-scratch poly-wrap, and steel strapping optimized for 40ft High Cube containers and curtain-sided mega-trailers, ensuring components arrive in Belgrade or Novi Sad pristine.
By eliminating regional middlemen, markups, and speculative stockholding fees, you gain enterprise-grade European standard racking directly from our modern manufacturing base at highly competitive project economics.
Concrete answers to technical, commercial, and logistical queries regarding racking procurement, customs clearance, and regulatory compliance in the Republic of Serbia.
Speak directly with our senior structural storage engineers. Share your pipe bundle dimensions, building drawings, and load criteria—our design office will deliver a comprehensive 2D/3D CAD warehouse layout, static calculation summary, and commercial quotation within 48 hours.
